I’m a Postdoctoral Research Associate at Carnegie Mellon University, working with Professor Xu Zhang. My research connects two-dimensional materials, device physics, and nanoelectronic integration.

I earned my Ph.D. in Materials Science and Engineering at KAUST, where I worked with Professor Mario Lanza. My work spans hBN gate dielectrics, transistor engineering, memristor reliability, and the integration of 2D materials into microchips.

Research projects

From two-dimensional materials to electronic devices and integrated circuits.

All selected publications
Device illustration showing a layered hBN gate dielectric above a MoS₂ channel, with gate, source, and drain electrodes
Device illustration · Yaqing Shen

ACS Nano · 2025

Low-voltage MoS₂ transistors

Abstract — summary

A 4 nm hBN gate dielectric and platinum electrode enable MoS₂ transistors with a threshold voltage of 0.46 V and an ON/OFF current ratio above 10⁵. Low gate leakage and continued operation after 1,000 switching cycles demonstrate the potential of ultrathin hBN for nanoscale transistors.

Read paper
Atomistic schematic comparing the penetration barriers of platinum and gold atoms into boron nitride
Shen et al. · Nature Electronics (2024), Fig. 4d

Nature Electronics · 2024

Reliable gate dielectrics for 2D transistors

Abstract — summary

Platinum and tungsten gate electrodes suppress leakage through CVD-grown hBN, enabling its use as a dielectric in 2D transistors. Measurements across 867 devices, including structures on a CMOS microchip, connect electrode selection with improved dielectric reliability.

Read paper
Complete Figure 5 with the hBN defect schematic, local resistance profile, and supporting microscopy panels
Shen et al. · Advanced Materials (2021), Fig. 5

Advanced Materials · 2021

Defects, variability & memristor yield

Abstract — summary

Local defects can limit the performance of devices made from 2D materials. This study shows that vertical hBN memristors tolerate many of these defects because current follows localized conductive paths, offering a route to circuits with improved yield and consistency.

Read paper
